Arista 7320X Series Technical Specifications

The Arista 7320X Series modular switches provide industry leading 40/100G density and performance. Available as a choice of 8 slot and 4 slot systems they combine wirespeed forwarding with comprehensive L2 and L3 features.

The 7320X Series supports high density layer 2/3/4 wirespeed performance linecards that offer a flexible combination of interface speeds including 10G, 25G, 40G and 100G to design large leaf and spine networks for scale-out of east-west traffic patterns with low latency and power efficiency and enable seamless migration from 10/40G to 25/100G soluitions.

7320X Specifications

System Performance:

The Arista 7320X systems can be fully populated with up to eight or four linecards respectively

  7328X 7324X
Description An 8 slot system with scalable density and performance for server or network rows replacing Nexus 7K or 9K Compact high density and resilient 100G system with flexible interface speeds for both spine and collapsed spline
Switching Capacity 50Tbps 25Tbps
Linecards 8 4
Maximum 100G Ports 256 128
Maximum 40G Ports 256 128
Maximum 10G Ports 1024 512
Maximum 25G Ports 1024 512
Maximum 50G Ports 512 256
L2/L3 PPS 38 Bpps 19 Bpps
Total Buffer 256MB 128MB
Rack Units 13 8

Linecard Specification

  7320X-32C
Ports 32 QSFP100
100GbE Interfaces 32 (QSFP100)
40GbE Interfaces 32 (QSFP+)
10GbE Interfaces 128 with breakout cable and optics
25GbE Interfaces 128 with breakout cable and optics
50GbE Interfaces 64 with breakout cable and optics
Packet Buffer 32MB
Nominal Power 219W
Maximum IPv4 Host Routes 104K
Maximum IPv6 Host Routes 52K
Maximum IPv4 Unicast Route Prefixes 128K
Maximum IPv6 Unicast Route Prefixes 84K
Maximum Multicast Groups 136K with 8K unique groups
Ingress / Egress ACLs 8K / 1K
Maximum LAG Members Up to 64 member ports
Maximum LAG Groups Up to 1024
Maximum ECMP Fanout 128-way
