Front Panel



This section describes the front panel of the Ethernet Switch.

CCS-720DP-48S

The CCS-720DP-48S front panel includes the following key components:

Figure 1. CCS-720DP-48S Front Panel


1

System Status LEDs

2

RJ45 Ethernet Management Port

3

USB Port

4

Console Port

5

Port LEDs

6

4x10G SFP+ Ports

7

SFP+ Port LEDs

8

48x1G PoE Ports

9

Mode Button

10

Mode Status LEDs

CCS-720DP-24S

The CCS-720DP-24S front panel includes the following key components:

Figure 2. CCS-720DP-24S Front Panel


1

System Status LEDs

2

RJ45 Ethernet Management Port

3

USB Port

4

Console Port

5

Port LEDs

6

4x10G SFP+ Ports

7

SFP+ Port LEDs

8

24x1G PoE Ports

9

Mode Button

10

Mode Status LEDs

CCS-720DT-48S

The CCS-720DT-48S front panel includes the following key components:

Figure 3. CCS-720DT-48S Front Panel


1

System Status LEDs

2

RJ45 Ethernet Management Port

3

USB Port

4

Console Port

5

Port LEDs

6

4x10G SFP+ Ports

7

SFP+ Port LEDs

8

48x1G PoE Ports

9

Mode Button

10

Mode Status LEDs

CCS-720DT-24S

The CCS-720DT-24S front panel includes the following key components:

Figure 4. CCS-720DT-24S Front Panel


1

System Status LEDs

2

RJ45 Ethernet Management Port

3

USB Port

4

Console Port

5

Port LEDs

6

4x10G SFP+ Ports

7

SFP+ Port LEDs

8

24x1G Ports

9

Mode Button

10

Mode status LEDs

CCS-720DF-48Y

The CCS-720DF-48Y front panel includes the following key components:

Figure 5. CCS-720DF-48Y Front Panel


1

System Status LEDs

2

RJ45 Ethernet Management Port

3

USB Port

4

Console Port

5

Port LEDs

6

4x25G SFP28 Ports

7

SFP28 Port LEDs

8

48x1G PoE Ports

9

Mode Button

10

Mode Status LEDs

CCS-720DP-24ZS

The CCS-720DP-24ZS front panel includes the following key components:

Figure 6. CCS-720DP-24ZS Front Panel


1

System Status LEDs

2

RJ45 Ethernet Management Port

3

USB Port

4

Console Port

5

Port LEDs

6

4x10G SFP+ Ports

7

SFP+ Port LEDs

8

24x1G PoE Ports

9

Mode Button

10

Mode Status LEDs

CCS-720DP-48ZS

The CCS-720DP-48ZS front panel includes the following key components:

Figure 7. CCS-720DP-48ZS Front Panel


1

System Status LEDs

2

RJ45 Ethernet Management Port

3

USB Port

4

Console Port

5

Port LEDs

6

4x10G SFP+ Ports

7

SFP+ Port LEDs

8

48x2.5G PoE Ports

9

Mode Button

10

Mode Status LEDs
