Part List
Each switch provides an accessory kit that contains parts that are required to install the switch. This appendix lists the installation parts contained in the switch accessory kit.
Rack Mount Parts
Describes the rack mounting parts and cables requied for installation of the device.
Two-Post Rack Mount Parts
This section describes the components included with the accessory kits available with the switches. Not all kits ship with all switches. Use only the parts shipped with the switch or optional, compatible kits. Do not mix parts from incompatible kits such as KIT-7001/2 and KIT-7101/2.
KIT-720XPM (Default)
The kit includes two-post rack mount parts and other components.
| Quantity | Description |
|---|---|
| 2 | Two-post brackets |
| 8 | M4 x 5 Flat head Phillips Screws |
KIT-7010-2POST-23 (Optional)
The kit includes two-post rack mount parts and other components.
| Quantity | Description |
|---|---|
| 2 | Two-post brackets 23" rack |
| 6 | M4 x 5 Flat head Phillips Screws |
KIT-7010-4POST (Optional)
The kit includes four-post rack mount parts and other components.
| Quantity | Description |
|---|---|
| 2 | Four-post rack mount kit |
| 6 | M4 x 5 Flat head Phillips Screws |
Cables
Lists the cables required for installation of the device.
| Quantity | Description |
|---|---|
| 1 | RJ-45 Patch Panel Cable |
| 1 | RJ-45 to DB9 Adapter and Cable |
| Optional (must be ordered separately) | |
| Power cables: Check for your region | |
