The following image displays the rear panel ports on the CCA-EMT-Q8 appliance and their descriptions.

1	12V 5A connector	5	Micro USB console port	9	10 Gbit SFP+ ports
2	Power on button	6	Console serial port	10	30W PoE ports
3	Reset button	7	USB ports	11	54V 1.2A connector
4	Factory reset button	8	LAN ports
