Arista 7280R3 Series 유니버설 리프 및 IP 스토리지 네트워크

차세대 클라우드, 컨텐츠 딜리버리, IP 스토리지, 리프 및 스파인 네트워크, 데이터 센터 상호 연결용으로 설계된 Arista 7280R3 Series 단독형 스위치에는 무손실 포워딩을 위한 동적 딥 버퍼링과 고밀도 100G 및 400G 이더넷, 인터넷 스케일 테이블 크기 및 최신 네트워크에 맞게 공간 및 전원 효율적인 풍부한 L2 및 L3 기능이 결합되어 있습니다.

가시성, 텔레메트리, 네트워크 모니터링, 정밀 타이밍, VXLAN 네트워크 가상화 및 다양한 자동화를 위한 고급 EOS® 기능이 방대한 하드웨어 리소스와 결합되어 있습니다. 집적도와 인터페이스 유형을 선택할 수 있는 7280R은 최신 데이터 센터에 존재하는 수많은 다양한 어플리케이션과 트래픽 패턴의 요구 사항을 충족합니다.

Arista 7280R3의 장점:

  • 무손실 포워딩을 위한 다이나믹 딥 버퍼 및 VOQ를 통해 최고의 성능 제공
  • 10G/25G/40G/50G/100G 및 400G까지 선택 가능한 유연한 설계
  • 고집적도 및 저전력의 인터넷 피어링을 위한 Arista FlexRoute™ 및 EOS NetDB™
  • 유연하고 확장 가능한 네트워크 정책 제어
  • 가속화된 임베디드 sFlow 및 IPFIX를 통해 대용량 네트워크 보안과 애플리케이션 모니터링 지원
  • 알고리즘 ACL 및 인밴드 네트워크 텔레메트리 등의 프로그래밍 가능 기능을 위한 유연한 파이프라인을 통해 플로우 및 패킷 포렌식 지원
  • 모든 레이어의 고급 트래픽 제어, 프로비저닝 및 모니터링을 위한 EOS 개방형 프로그래밍 기능
  • 일관된 기능과 입증된 아키텍처를 사용하는 4세대 딥 버퍼 고정형 시스템

주요 비디오: Arista R3 Series 소개

Arista 7280R3 Series FlexRoute 엔진 및 EOS NetDB에서는 최저 전력 소비율과 2.5백만 개의 라우트까지 확장되는 빠른 집중성을 통해 인터넷 IP 라우팅 스케일을 지원하는 확장성을 제공하면서 다양한 네트워크 역할에 맞는 유연한 포워딩 프로필을 선택할 수 있습니다.

Arista 알고리즘 ACL을 사용하면 필터링을 위한 추가 기능을 제공하면서 전체 포워딩 기능 외에도 모든 인터페이스의 sFlow 샘플링 기능과 결합된 확장된 패턴 일치 기능을 통해 높은 수준으로 유연하게 액세스를 제어할 수 있습니다.

400G를 통한 유연한 솔루션

  • 2RU에서 최대 48개의 400G 포트와 19.2Tbps의 와이어 속도 성능
  • 4개의 400G 업링크가 있는 고밀도 와이어 속도 1RU 32포트 100G 시스템
  • 유니버설 리프 및 스파인 설계를 위해 400G 및 100G 시스템이 혼재되어 있는 광범위한 1RU 및 2RU 시스템
  • Arista FlexRoute를 통한 인터넷 피어링 확장성
  • 시스템당 최대 32GB의 고대역 울트라 딥 패킷 버퍼

Arista EOS

  • 개방형 확장성 및 프로그래밍 기능
  • SDCN(Software Driven Cloud Networking)
  • 정밀한 모듈단위의 메모리 보호 아키텍처
  • Linux 도구 액세스
  • in-service 소프트웨어 패치 및 자가 치유형 SFR(스테이플한 폴트 복구)

데이터 센터용으로 최적화

  • OSFP 및 QSFP-DD가 있는 400G 및 100G 인터페이스 중에서 유연하게 선택 가능
  • 100G 포트당 18W 미만 및 다양한 기능 제공
  • L2 및 L3을 통한 최대 256방향 다중경로
  • 뛰어난 전력 효율로 총 소유 비용 감소
  • 전원 및 쿨링 핫스왑 ,이중화 제공
  • 제1 통신서비스 사업자를 위한 NEBS 표준 준수

다양한 기능 세트 및 개방형 프로그래밍 기능

  • 신속한 복구 기능을 제공하는 포괄적인 스위칭 및 라우팅 기능 세트
  • IX 제공업체와 클라우드 WAN용 세그먼트 라우팅 및 EVPN 서비스
  • IPv6 오버레이 및 언더레이 지원
  • 대규모의 완벽한 기능을 제공하는 IPv4 / IPv6, ACL, QoS
  • VXLAN 및 256방향 다중경로
  • LANZ를 통한 마이크로버스트 감지
  • VXLAN 및 EOS Network Tracer
  • CloudVision®을 통한 워크플로우 자동화 및 오케스트레이션
  • sFlow 가속화를 통해 대용량 네트워크 보안과 애플리케이션 모니터링 지원
  • 인밴드 네트워크 텔레메트리를 통해 대규모 플로우 및 패킷 포렌식 지원
  • 광범위하고 유연한 카운터를 통해 실시간 모니터링 및 문제점 해결

Arista 7280R3 Series 기술 사양

Arista 7280R3 Series는클라우드 DC, 컨텐츠 딜리버리, IP 스토리지, 엔터프라이즈 리프 및 스파인 네트워크와 데이터 센터 상호 연결 및 IP 피어링 등의 최고 성능의 환경을 제공하기 위해 특수 목적으로 설계된 100/400G 단독형 1RU 및 2RU 시스템입니다.

와이어 속도 L2 및 L3 포워딩이 네트워크 가상화, 개방형 모니터링 및 네트워크 분석, 복구 기능, 아키텍처 유연성과 같은 고급 기능과 결합되어 있으며 확고한 성능을 제공합니다. 딥 패킷 버퍼 및 대규모 라우팅 테이블은 인터넷 피어링 어플리케이션을 사용할 수 있게 해주며 다양한 인터페이스 및 집적도 선택은 구축의 유연성을 제공합니다.

모든 Arista 7280R3 Series에서는 FlexRoute™ 엔진을 지원하므로 인터넷 스케일의 라우팅 지원을 통해 라우팅 플랫폼으로서 구축될 수 있도록 확장성을 제공합니다. Arista FlexRoute는 EOS NetDB™와 함께 상용 칩셋에서 기본적으로 제공할 수 없는 혁신과 컨버전스를 가능하게 해줍니다. 7280R3K Series에서는 최대 2.5M IP 라우트를 포함하여 여러 다른 네트워크 역할에 맞게 공통 리소스를 활용하는 일련의 유연한 프로필을 지원합니다.

7280R3의 이점

  • 표준 기반 고집적 400G 및 100G 스위치는 검증된 미래형 설계와 고성능 스토리지나 CDN과 같은 고대역폭 요구 사항에 적합함
  • 고정 폼 팩터의 다이나믹 딥 버퍼를 갖추고 있어 데이터 분석, IP 스토리지 등과 같이 무손실 성능 및 폭주 트래픽이 문제가 되는 경우에 적합한 스파인 스위치임
  • 고성능 및 예측 가능한 레이턴시가 필요한 스토리지 시스템에 40G 및 50G로 직접 연결
  • CloudVision®을 통한 고급 분석을 위하여 네트워크 상태정보를 스트리밍해 줌
  • 와이어 속도 VXLAN 라우팅을 지원함으로써 차세대 클라우드 버스팅을 대비한 네트워크 차원의 가상화 플랫폼임
  • 하드웨어 지원 PTP를 통해 별도의 타이밍 네트워크에 대한 고가의 투자 없이도 이더넷 기반 네트워크 전체에서 정확한 타이밍 솔루션 사용 가능
  • 고유한 모니터링 및 프로비저닝 기능 – LANZ, DANZ, AEM, IEEE 1588 PTP, ZTP, VM Tracer, VXLAN, eAPI
  • 특정 공급자 솔루션에 얽매이지 않는 개방형 멀티 벤더 네트워크를 위한 포괄적인 L2 및 L3 기능 세트 제공
  • 네트워크 포렌직을 위한 가속화된 sFLow 및 IPFIX
  • 대규모 L2 및 L3 테이블 자원으로 어떠한 워크로드에도 적합한 대형 L2 및 L3 환경 모두에 구축될 수 있는 유연성 제공
  • NEBS 표준 준수 및 DC 전원 공급 장치를 제공함으로써 통신 서비스 사업자 환경에 적합하게 설계됨

Arista 7280R3 Series


7280PR3
400G 7280PR3 Series 및 7280DR3 Series
  • 400G 1RU 및 2RU 시스템
  • 유연한 100G, 50G 및 400G 지원을 위한 OSFP 또는 QSFP-DD를 사용하는 고밀도 400G 포트
  • 최대 384개의 50GbE 포트 또는 192개의 100G 포트
  • 울트라 딥 및 다이내믹 버퍼로 최대 19.2Tbps의 와이어스피드 성능 제공
  • FlexRoute로 최대 130만 개 IPv4/v6 라우트 지원
  • 7280PR3K Series 및 FlexRoute로 최대 250만개 IPv4/v6 라우트 지원
  • 모든 모델에서 확장 가능한 가속화된 sFlow
7280CR3
7280CR3 Series
  • 100G 1RU 및 2RU 시스템에서 QSFP100 광모듈 및 케이블로 포트 조합 선택 가능
  • 2RU에서 최대 96개 포트(100G)와 1RU에서 48개 포트
  • 10/25/40/50/100G 및 400G에 대한 유연한 인터페이스 조합
  • 16GB의 버퍼로 최대 9.6Tbps의 와이어스피드 성능 제공
  • FlexRoute로 최대 130만 개 IPv4/v6 라우트 지원
  • 7280CR3K Series 및 FlexRoute로 최대 250만개 IPv4/v6 라우트 지원
  • 모든 모델에서 확장 가능한 가속화된 sFlow

확장성:

각 7280R3 Series 시스템에서는 예측 가능한 확장 기능을 통해 레이어 2 및 레이어 3 데이터 센터 설계를 지원하는 일관된 기능들을 제공합니다. Arista의 FlexRoute 엔진은 다양한 IP/MPLS/VXLAN 프로토콜을 지원하여 완전한 인터넷 라우팅을 가능하게 해줍니다.

포트

7280R3 Series

7280R3K Series
프로필 균형 잡힘 L3 균형 잡힘 L3 L2
MAC 주소 448K 128K 768K 160K 1.4M
IPv4 호스트 라우트 896K 256K 1.4M 320K 2.8M
IPv6 유니캐스트 호스트 라우트 224K 64K 368K 80K 736K
IPv4 유니캐스트 LPM 라우트 704K 1.3M 1.2M 2.5M 128K
IPv6 유니캐스트 LPM 라우트 235K 440K 411K 821K 42K
멀티캐스트 라우트 448K 128K 736K 160K 1.4M
ACL 항목 24K 24K 24K 24K 24K
최대 ECMP 256방향 256방향 256방향 256방향 256방향

The Arista 7280R3A Modular Series are purpose built 100G and 400G systems built for the highest performance environments, and to meet the needs of the largest scale data centers and service providers. They deliver scalable L2 and L3 resources and high density with advanced features for network monitoring, precision timing and network virtualization to deliver scalable and deterministic network performance while simplifying designs and reducing Opex.

The modular 7280R3A system provides 14.4 Tbps of packet processing in an extremely compact and power efficient 4RU form factor providing flexibility to deploy a range of interface types. Line rate performance with up to 144 ports of 100G or 36 ports of 400G is combined with rich functionality for a wide range of open networking solutions including large scale layer 2 and layer 3 cloud designs, overlay networks, virtualized or traditional enterprise data center networks. Deep packet buffers and large routing tables allow for internet peering and secure data center interconnect applications and provide complete deployment flexibility.

Each 7280R3 modular system is configurable with SFP, QSFP and OSFP/QSFP-DD interfaces to support connectivity from 10G to 400G and supports dense 400G-ZR DWDM. Further options include large scale routing and policy resources and Arista TunnelSec for strong encryption at layer 2 or layer 3.

All elements of the 7280R3A modular are field replaceable, and optimized for simple maintenance, a broad range of network interfaces with a choice of industry standard interfaces allowing for easy transitions to the latest 100G/400G networks. Combined with Arista EOS the 7280R3A series deliver advanced features for high performance large scale layer 2 and layer 3 cloud designs, enterprise data centers and service provider networks.

Introducing the 7280R3 Modular Series

Arista R3 Series Family Datasheet

7280R3 Modular Series Technical Specifications

  7289R3A-SC 7289R3AM-SC 7289R3AK-SC
Description R3A Switchcard for 7280R Modular R3A Switchcard with Encryption for 7280R Modular Large Scale R3A Switchcard with Encryption for 7280R Modular
Max 400G 36 36 36
Max 200G 72 72 72
Max 100G 144 144 144
Max 50G 144 144 144
Max 40G 144 144 144
Max 25G 144 144 144
Max 10G 144 144 144
L2/3 Throughput (FDX) 14.4 (28.8) Tbps 14.4 (28.8) Tbps 14.4 (28.8) Tbps
L2/3 PPS 5.4 Bpps 5.4 Bpps 5.4 Bpps
Latency From 3.8 usec From 3.8 usec From 3.8 usec
Typical System Power Draw 1244W 1244W 1244W
Total System Buffer 16 GB 16 GB 16 GB
Rack Units 4 4 4
MACsec/IPSec Encryption - All Ports All Ports
Large Scale Routing & Policy - - Yes
CloudVision Yes Yes Yes
Smart System Upgrade* Yes Yes Yes
ZTP Yes Yes Yes
VM Tracer Yes Yes Yes
AEM Yes Yes Yes
VXLAN Yes Yes Yes
LANZ Yes Yes Yes
Accelerated sFlow Yes Yes Yes
Airflow Yes Yes Yes
AC and DC PSU Yes Yes Yes

Arista 7280R3 Series Fixed Systems Comparisons

The Arista 7280R3 Series of fixed systems delivers a comprehensive selection of scale and connectivity options to suit a wide range of use cases.

Systems are available with SFP, QSFP and OSFP/QSFP-DD to support connectivity from 1G to 400G, further options include large scale routing and policy resources, Arista TunnelSec for strong encryption at layer 2 or layer 3, Synchronous Ethernet and support for dense 400G-ZR DWDM.

Introducing the 7280R3 Series

Arista R3 Series Family Datasheet

The following tables provide an overview of all Arista 7280R3 Series models grouped by interface type. For a complete catalog of Arista 7000 Series switch specifications click here.

7280R3 400G Systems Specifications

  7280DR3A-54
Series
7280DR3A-36
Series
7280PR3-24
Series
7280DR3-24
Series
Description 54 x QSFP-DD 36 x QSFP-DD 24 x OSFP 24 x QSFP-DD
Max 400G 54 36 24 24
Max 200G 108 72 48 48
Max 100G 216 144 96 96
Max 50G 348 232 192 192
Max 40G 54 36 24 24
Max 25G 348 232 192 192
Max 10G 348 232 192 192
L2/3 Throughput (FDX) 21.6 (43.2) Tbps 14.4 (28.8) Tbps 9.6 (19.2) Tbps 9.6 (19.2) Tbps
L2/3 PPS 8.1 Bpps 5.4 Bpps 4 Bpps 4 Bpps
Latency From 3.8 usec From 3.8 usec From 3.8 usec From 3.8 usec
Typical System Power Draw 933W 643W 650W 650W
Total System Buffer 24 GB 16 GB 16 GB 16 GB
Rack Units 2 2 1 1
Sync-E Support Inband +
PPS/10M/ToD
Inband +
PPS/10M/ToD
- -
MACsec/IPsec Encryption All Ports
(R3AM, R3AK)
All Ports
(R3AM, R3AK)
- -
Large Scale Routing & Policy R3AK R3AK R3AK R3AK
CloudVision Yes Yes Yes Yes
Smart System Upgrade* Yes Yes Yes Yes
ZTP Yes Yes Yes Yes
VM Tracer Yes Yes Yes Yes
AEM Yes Yes Yes Yes
VXLAN Yes Yes Yes Yes
LANZ Yes Yes Yes Yes
Accelerated sFlow Yes Yes Yes Yes
Airflow Front to Rear
AC and DC PSU Yes Yes Yes Yes



7280R3 100G/400G Systems Specifications

  7280CR3A-24D12
Series
7280CR3A-48D6
Series
7280CR3-32P4
Series
7280CR3-32D4
Series
Description 24 x QSFP
12 x QSFP-DD
48 x QSFP
6 x QSFP-DD
32 x QSFP
4 x OSFP
32 x QSFP
4 x QSFP-DD
Max 400G 12 6 4 4
Max 200G 36 12 8 8
Max 100G 72 68 48 48
Max 50G 112 114 96 96
Max 40G 36 54 36 36
Max 25G 112 114 96 96
Max 10G 112 114 96 96
L2/3 Throughput (FDX) 7.2 (14.4) Tbps 7.2 (14.4) Tbps 4.8 (9.6) Tbps 4.8 (9.6) Tbps
L2/3 PPS 2.7 Bpps 2.7 Bpps 2 Bpps 2 Bpps
Latency From 3.8 usec From 3.8 usec From 3.8 usec From 3.8 usec
Typical System Power Draw 346W TBD 535W 535W
Total System Buffer 8 GB 8 GB 8 GB 8 GB
Rack Units 1 2 1 1
Sync-E Support Inband +
PPS/10M/ToD
Inband +
PPS/10M/ToD
- -
MACsec/IPsec Encryption All Ports
(R3AM, R3AK)
All Ports
(R3AM, R3AK)
100G Ports
(R3MK)
100G Ports
(R3MK)
Large Scale Routing & Policy R3AK R3AK R3AK, RMK R3K, R3MK
CloudVision Yes Yes Yes Yes
Smart System Upgrade* Yes Yes Yes Yes
ZTP Yes Yes Yes Yes
VM Tracer Yes Yes Yes Yes
AEM Yes Yes Yes Yes
VXLAN Yes Yes Yes Yes
LANZ Yes Yes Yes Yes
Accelerated sFlow Yes Yes Yes Yes
Airflow Front to Rear and Rear to Front
AC and DC PSU Yes Yes Yes Yes

  7280CR3-36S
Series
7280CR3A-32S
Series
Description 28 x QSFP
6 x QSFP200
2 x QSFP-DD
30 x QSFP100/200
2 x QSFP200/QSFP-DD
Max 400G 2 2
Max 200G 8 18
Max 100G 40 36
Max 50G 80 56
Max 40G 36 36
Max 25G 120 56
Max 10G 120 56
L2/3 Throughput (FDX) 2.4 (4.8) Tbps 3.6 (7.2) Tbps
L2/3 PPS 1 Bpps 1.35 Bpps
Latency From 3.8 usec From 3.8 usec
Typical System Power Draw 254W TBD
Total System Buffer 4 GB 4 GB
Rack Units 1 1
Sync-E Support - Inband +
PPS/10M/ToD
MACsec/IPsec Encryption - All Ports
(R3AM, R3AK)
Large Scale Routing & Policy R3K R3AK
CloudVision Yes Yes
Smart System Upgrade* Yes Yes
ZTP Yes Yes
VM Tracer Yes Yes
AEM Yes Yes
VXLAN Yes Yes
LANZ Yes Yes
Accelerated sFlow Yes Yes
Airflow Front to Rear and Rear to Front
AC and DC PSU Yes Yes



7280R3 25G/100G Systems Specifications

  7280CR3-96
Series
7280CR3A-72
Series
7280SR3A-48YC8
Series
7280SR3-48YC8
Series
Description 96 x QSFP 72 x QSFP 4 x QSFP200
4 x QSFP100
48 x SFP 10/25/50G
8 x QSFP
48 x SFP 1/10/25G
Max 400G - - - -
Max 200G - 36 6 -
Max 100G 96 72 8 8
Max 50G 192 102 48 16
Max 40G 96 72 8 8
Max 25G 192 102 48 80
Max 10G 192 102 48 80
L2/3 Throughput (FDX) 9.6 (19.2) Tbps 7.2 (14.4)
Tbps
3.6 (7.2)
Tbps
2.4 (4.8) Tbps
L2/3 PPS 4 Bpps 2.7 Bpps 1.35 Bpps 1 Bpps
Latency From 3.8 usec From 3.8 usec From 3.8 usec From 3.8 usec
Typical System Power Draw 1003W TBD TBD 154W
Total System Buffer 16 GB 8 GB 4 GB 4 GB
Rack Units 2 2 1 1
Sync-E Support - Inband + PPS/10M/ToD Inband + PPS/10M/ToD -
MACsec/IPsec Encryption - All Ports
(R3AM, R3AK)
All Ports
(R3AM, R3AK)
All Ports
(MACsec only R3M)
Large Scale Routing & Policy R3K R3AK R3AK R3K
CloudVision Yes Yes Yes Yes
Smart System Upgrade* Yes Yes Yes Yes
ZTP Yes Yes Yes Yes
VM Tracer Yes Yes Yes Yes
AEM Yes Yes Yes Yes
VXLAN Yes Yes Yes Yes
LANZ Yes Yes Yes Yes
Accelerated sFlow Yes Yes Yes Yes
Airflow Front to Rear Front to Rear and Rear to Front
AC and DC PSU Yes Yes Yes Yes

  7280SR3-40YC6
Series
7280TR3-40C6
Series
Description 6 x QSFP
40 x SFP 1/10/25G
6 QSFP
40 x RJ45 1/10G
Max 400G - -
Max 200G - -
Max 100G 6 6
Max 50G 12 12
Max 40G 6 6
Max 25G 52 12
Max 10G 52 52
L2/3 Throughput (FDX) 800 (1600) Gbps 800 (1600) Gbps
L2/3 PPS 600 Mpps 600 Mpps
Latency From 3.8 usec From 3.8 usec
Typical System Power Draw 130W 186W
Total System Buffer 2 GB 2 GB
Rack Units 1 1
Sync-E Support Inband Only (SR3E) -
MACsec/IPsec Encryption - -
Large Scale Routing & Policy - -
CloudVision Yes Yes
Smart System Upgrade* Yes Yes
ZTP Yes Yes
VM Tracer Yes Yes
AEM Yes Yes
VXLAN Yes Yes
LANZ Yes Yes
Accelerated sFlow Yes Yes
Airflow Front to Rear and Rear to Front
AC and DC PSU Yes Yes


1-400G Wire-speed Encryption

Deploying high performance, scalable bulk data encryption cost effectively is a major challenge for cloud data centers, enterprises and service providers. Arista 7280R3M, 7280R3AM and 7280R3AK Series platforms provide wire speed AES-256-GCM strong encryption for mixed speeds from 1G to 400G offering comprehensive choices for secure connectivity within facilities and over the wide area at an efficient cost point.

All 7280R3M, R3AM and R3AK systems provide standards-based IEEE 802.1AE MACsec for line-rate frame encryption and authentication. This ensures confidentiality as well as providing anti-replay protection and therefore confidence in the integrity of encrypted traffic.

Arista TunnelSec provides advanced encryption and is available on 7280R3AM and R3AK systems. TunnelSec is a standards-based approach to increasing the performance and utility of strong encryption for modern networks. TunnelSec adds support for IPsec and VXLANsec in addition to MACsec. IPsec and VXLANsec both enable the construction of encrypted IP tunnels that traverse multiple unencrypted hops between endpoints. IPsec operates router-to-router, while VXLANsec provides VTEP level integration for simple deployment of encrypted overlays. Both IPsec and VXLANsec provide a solution to line-rate strong encryption across third party infrastructure for WAN or DCI deployments.

MACsec, IPsec and VXLANsec solutions leverage AES-256-GCM for strong bulk encryption and operate at full line rate. The flexibility provided by offering encryption at different network layers enables a broad range of deployments and removes the need for additional encryption devices while providing orders of magnitude improvements in latency and throughput when compared to traditional appliances.

Key Benefits

  • Provides high performance L2 and L3 features with wire speed MACsec and IPsec encryption in compact form factors.
  • Multi-speed support for 10/25/40/50/100/200 and 400G
  • Eliminates the need for external encryption devices.
  • Provide secure communication for a wide range of applications from large scale leaf and spine networks to data center interconnect.
  • Unparalleled Performance with Dynamic Deep Buffers and VOQ for Lossless forwarding.
  • Embedded Accelerated sFlow and IPFIX for high capacity network security and application monitoring.
  • Flexible pipeline for programmable features including Algorithmic ACLs and Inband Network Telemetry for flow and packet forensics.

Key Features

  • High Density wirespeed systems with up to:
    • 54 x 400G
    • 144 x 100G QSFP
    • 48 x 1/10/25G and 8 x 100G
  • Up to 21.6 Tbps of wire speed L2 and L3 IP forwarding
  • IEEE 802.1AE MACsec encryption on 25G SFP, 100G QSFP and 400G OSFP / QSFP-DD ports
  • IPsec UDP-ESP (RFC 4303, RFC 3948)
  • Internet scale IPv4 and IPv6 forwarding tables
  • Pluggable optics for pay as you grow expansion
  • Comprehensive switching and routing feature set with rapid convergence
  • Segment Routing and EVPN Services for IX Providers and Cloud WAN
  • IPv6 Overlay and Underlay support
  • Large scale full featured IPv4 / IPv6, ACLs, and QoS
  • VXLAN and 512-way multi-pathing
  • LANZ for Microburst Detection
  • VXLAN and EOS Network Tracers
  • CloudVision® for Workflow Automation and Orchestration
  • Inband Network Telemetry for flow and packet forensics at scale
  • Extensive and flexible counters for real-time monitoring and troubleshooting

7280R3 400G Systems Specifications

  7280R3 Modular
7289R3AM-SC
7289R3AK-SC
7280DR3AM-54
7280DR3AK-54
7280DR3AM-36
7280DR3AK-36
Description 36 x OSFP or
QSFP-DD or
144 x QSFP
54 x QSFP-DD 36 x QSFP-DD
Max 400G 36 54 36
Max 200G 72 108 72
Max 100G 144 216 144
Max 50G 144 348 232
Max 40G 144 54 36
Max 25G 144 348 232
Max 10G 144 348 232
Max 1G - - -
L2/3 Throughput (FDX) 14.4 (28.8) Tbps 21.6 (43.2) Tbps 14.4 (28.8) Tbps
L2/3 PPS 5.4 Bpps 8.1 Bpps 5.4 Bpps
Latency From 3.8 usec From 3.8 usec From 3.8 usec
Typical System Power Draw - 933W 643W
Total System Buffer 16 GB 24 GB 16 GB
Rack Units 4 2 2
Sync-E Support - Inband + PPS/10M/ToD* Inband + PPS/10M/ToD*
MACsec/IPsec Encryption All Ports All Ports All Ports
Large Scale Routing & Policy R3AK R3AK R3AK
CloudVision Yes Yes Yes
Smart System Upgrade* Yes Yes Yes
ZTP Yes Yes Yes
VM Tracer Yes Yes Yes
AEM Yes Yes Yes
VXLAN Yes Yes Yes
LANZ Yes Yes Yes
Accelerated sFlow Yes Yes Yes
Airflow Front to Rear
AC and DC PSU Yes Yes Yes



7280R3 100G/400G Systems Specifications

  7280CR3AM-24D12
7280CR3AK-24D12
7280CR3AM-48D6
7280CR3AK-48D6
7280CR3MK-32P4S 7280CR3MK-32D4S
Description 24 x QSFP
12 x QSFP-DD
48 x QSFP
6 x QSFP-DD
32 x QSFP
4 x OSFP
32 x QSFP
4 x QSFP-DD
Max 400G 12 6 4 4
Max 200G 36 12 8 8
Max 100G 72 68 48 48
Max 50G 112 114 96 96
Max 40G 36 54 36 36
Max 25G 112 114 96 96
Max 10G 112 114 96 96
Max 1G - - - -
L2/3 Throughput (FDX) 7.2 (14.4) Tbps 7.2 (14.4) Tbps 4.8 (9.6) Tbps 4.8 (9.6) Tbps
L2/3 PPS 2.7 Bpps 2.7 Bpps 2 Bpps 1 Bpps
Latency From 3.8 usec From 3.8 usec From 3.8 usec From 3.8 usec
Typical System Power Draw TBD TBD 535W 535W
Total System Buffer 8 GB 8 GB 8 GB 8 GB
Rack Units 1 1 1 1
Sync-E Support Inband + PPS/10M/ToD* Inband + PPS/10M/ToD* - -
MACsec/IPsec Encryption All Ports All Ports QSFP28 Ports QSFP28 Ports
Large Scale Routing & Policy R3AK R3AK R3MK R3MK
CloudVision Yes Yes Yes Yes
Smart System Upgrade* Yes Yes Yes Yes
ZTP Yes Yes Yes Yes
VM Tracer Yes Yes Yes Yes
AEM Yes Yes Yes Yes
VXLAN Yes Yes Yes Yes
LANZ Yes Yes Yes Yes
Accelerated sFlow Yes Yes Yes Yes
Airflow Front to Rear and Rear to Front
AC and DC PSU Yes Yes Yes Yes



7280R3 25G/100G Systems Specifications

  7280CR3AM-72
7280CR3AK-72
7280SR3M-48YC8
Description 72 x QSFP 8 x QSFP
48 x SFP 1/10/25G
Max 400G - -
Max 200G 36 -
Max 100G 72 8
Max 50G 102 16
Max 40G 72 8
Max 25G 102 80
Max 10G 102 80
Max 1G - 48
L2/3 Throughput (FDX) 7.2 (14.4) Tbps 2.4 (4.8) Tbps
L2/3 PPS 2.7 Bpps 1 Bpps
Latency From 3.8 usec From 3.8 usec
Typical System Power Draw TBD 154W
Total System Buffer 8 GB 4 GB
Rack Units 2 1
Sync-E Support Inband + PPS/10M/ToD* -
MACsec/IPsec Encryption All Ports (R3AM, R3AK) All Ports (MACsec only)
Large Scale Routing & Policy R3AK -
CloudVision Yes Yes
Smart System Upgrade* Yes Yes
ZTP Yes Yes
VM Tracer Yes Yes
AEM Yes Yes
VXLAN Yes Yes
LANZ Yes Yes
Accelerated sFlow Yes Yes
Airflow Front to Rear and Rear to Front
AC and DC PSU Yes Yes

*SyncE is a roadmap feature

Scalability:

Each 7280R3/R3A Series system delivers a consistent set of features supporting layer 2 and layer 3 data center designs with predictable and linear scaling. Arista's FlexRoute Engine enables full Internet routing coupled with support for a variety of IP/MPLS/VXLAN protocols.

Resources1 7280R3/R3A Series 7280R3K/R3AK Series
Profile L3-Profile
(default)
Balanced Profile L3-XL Profile
(default)
L3-XXL Profile L3-XXXL Profile Balanced-XL Profile
ARP Entries 88K 88K 112K 112K 80K 96K
MAC Addresses 224K 224K 256K 192K 384K 256K
IPv4 Unicast Routes 1450K 800K 2250K 2850K 3950K 1850K
Additional IPv4 Unicast Routes with FlexRoute +1792K +1792K +2048K +1536K +3072K +2048K
IPv6 Unicast Host Routes 433-483K 250-267K 683-750K 833-950K 1100-1317K 567-617K
Multicast Routes 128K 128K 128K 128K 128K 128K
TCAM ACL Entries (Per chip) 24K 24K 24K 24K 24K 24K
Traffic Policy ACL IPv4 Prefixes 30K 30K 430K 296K 30K 430K
Traffic Policy ACL IPv6 Prefixes 10K 10K 150K 100K 10K 150K
ECMP 512-Way 512-Way 512-Way 512-Way 512-Way 512-Way

1 Undimensional scaling maxima with currently available MDB profiles. Available resources depend on user configuration.
