Front Panel

This appendix displays the front panel of all switches covered by this guide.

Note: Depending on the components used to populate the chassis, the appearance of a specific switch could be different.



Note: All switches are designed to fit in 19-inch racks.
Figure 1. DCS-7804 Front Panel (Fully Populated)

1 Power supplies 4 Line cards 7 Supervisor lock
2 Line card and Supervisor extraction tool tether 5 Line card lock 8 Grounding locations
3 Extraction tool 6 Supervisor modules 9 ESD attach point



Figure 2. DCS-7808 Front Panel (Fully Populated)

1 Power supplies 4 Line cards 7 Supervisor lock
2 Line card and Supervisor extraction tool tether 5 Line card lock 8 Grounding locations
3 Extraction tool 6 Supervisor modules 9 ESD attach point



Figure 3. DCS-7812 Front Panel (Fully Populated)

1 Power supplies 4 Line cards 7 Supervisor lock
2 Line card and Supervisor extraction tool tether 5 Line card lock 8 Grounding locations
3 Extraction tool 6 Supervisor modules 9 ESD attach point



Figure 4. DCS-7816 Front Panel (Fully Populated)

1 Power supplies 6 Supervisor modules 11 Extraction tool
2 Line card and Supervisor extraction tool tether 7 Supervisor lock 12 Grounding locations
3 Extraction tool 8 Line cards 13 ESD attach point
4 Line cards 9 Line card lock
5 Line card lock 10 Line card and Supervisor extraction tool tether
