Front Panel

This section displays the front panel of all switches covered by this guide.



Figure 1. CCS-720XP-96ZC2

1 System status LED 5 USB port 9 5G PoE ports
2 Fan status LED 6 Console serial port 10 2.5G PoE ports
3 PSU status LED 7 25G ports
4 Ethernet management port 8 100G ports



Figure 2. CCS-720XP-96ZC2-M-S

1 System status LED 5 USB port 9 5G PoE ports
2 Fan status LED 6 Console serial port 10 2.5G PoE ports
3 PSU status LED 7 25G ports
4 Ethernet management port 8 100G ports
