Parts List

Each switch provides an accessory kit that contains parts that are required to install the switch. This appendix lists the installation parts contained in the switch accessory kit.

The following topics are covered in this section:

Rack Mount Parts

Four-Post Rack Mount Parts

Figure 1. Four-Post Rack Mount Parts

1 Rail Slide 3 Assembled Rail
2 Rail Rod 4 Rack Plugs



Two-Post Rack Mount Parts

Figure 2. Two-Post Rack Mount Parts

1 Mounting Ear (Left)
2 Mounting Ear (Right)



Cables

Quantity Description
2 Power cables: IEC-320/C13-C14, 13 A, 250 V
1 RJ-45 Patch Panel Cable
1 RJ-45 to DB9 Adapter Cable



Warning: All provided power cables are for use only with Arista products.
