Parts List
Each switch provides an accessory kit that contains parts that are required to install the switch. This appendix lists the installation parts contained in the switch accessory kit.
Note The accessory kit is included in a bag. For DCS-7020SR-32C2, four-post rack kit is optional and sold separately.
B.1 Rack Mount Parts
B.1.1 Four-Post Rack Mount Parts
Figure B-1: Four-Post Rack Mount Parts

B.1.2 Two-Post Rack Mount Parts
Figure B-2: Two-Post Rack Mount Parts for DCS-7020SR-32C2
B.2 Cables

Quantity
Description
2
Power cables: IEC-320/C13-C14, 13 A, 250 V
1
RJ-45 Patch Panel Cable
1
RJ-45 to DB9 Adapter Cable
Warning All provided power cables are for use only with Arista products.
